产品型号: advantec Nylon Membrane Filters
产品展商: 其他品牌
简单介绍
Nylon Membrane Filters High strength and heat resistance Inherently hydrophilic membranes made by impregnating a polyester web with nylon Compatible with many aqueous and alcoholic solv
advantec Nylon尼龙膜的详细介绍
| Nylon Membrane Filters |
|
|
High strength and heat resistance |
|
|
Inherently hydrophilic membranes made by impregnating a polyester web with nylon |
|
|
Compatible with many aqueous and alcoholic solvents and solutions |
|
|
Pure; negligible organic extractables |
|
|
Binds proteins, DNA, and RNA |
|
|
Use for HPLC sample preparation, to sterilize biological solutions or buffers, or for vacuum degassing |
|
|
Magnification of Nylon filter. |
|
|
|
| |
| Product Specifications: Nylon Membrane Filters |
| Click here for chemical compatiblity information. |
|
Pore Size
(μm)
|
Bubble Point1
|
Flow Rates2
|
|
MPa
|
psi
|
Water
(mL/min/cm2)
|
Air
(L/min/cm2)
|
|
0.10
|
≥0.48
|
≥70
|
4.0
|
0.6
|
|
0.22
|
≥0.34
|
≥50
|
9.9
|
1.7
|
|
0.45
|
≥0.20
|
≥30
|
26.9
|
3.2
|
|
0.65
|
≥0.12
|
≥18
|
59.3
|
4.5
|
|
0.80
|
≥0.089
|
≥13
|
80.5
|
14
|
|
1.20
|
≥0.075
|
≥11
|
180
|
18
|
|
5.00
|
≥0.041
|
≥6
|
331
|
34
|
|
|
|
|
Wetting Time: <3 seconds to wet a φ47mm disk with aqueous 1% methylene blue |
|
|
Maximum Operating Temperature: 180°C |
|
|
Thickness: 65-120μm |
|
|
Extractables: <0.2% |
|
|
BSA Protein Binding: 120μg/cm2 |
| |
| Notes: |
| 1. |
Bubble Point is the minimum pressure required to force air through a membrane which has been prewet with water |
| 2. |
Flow Rate indicates initial flow rate at 10 psi
Water: using prefiltered (0.1μm) water
Air: using prefiltered nitrogen |
|
| |
| Ordering Information: Nylon Membrane Filters |
Choose the appropriate Pore Size and Membrane Diameter from the chart below to select a catalog number. Nylon Membrane filters are available as nonsterile, plain white disks in the packaging listed below. Product certification is available upon request.
For price and availablity of any membrane filter, call us at 1-800-334-7132 or click here to contact us by email. |
| |
Plain White Disks
|
Pore Size
(μm)
|
φ13 mm
|
φ25 mm
|
φ47 mm
|
φ90 mm
|
φ142 mm
|
φ293 mm
|
|
Package of 100
|
Package of 25
|
|
0.10
|
N010A013A
|
N010A025A
|
N010A047A
|
N010A090C
|
N010A142C
|
N010A293C
|
|
0.22
|
N022A013A
|
N022A025A
|
N022A047A
|
N022A090C
|
N022A142C
|
N022A293C
|
|
0.45
|
N045A013A
|
N045A025A
|
N045A047A
|
N045A090C
|
N045A142C
|
N045A293C
|
|
0.65
|
N065A013A
|
N065A025A
|
N065A047A
|
N065A090C
|
N065A142C
|
N065A293C
|
|
0.80
|
N080A013A
|
N080A025A
|
N080A047A
|
N080A090C
|
N080A142C
|
N080A293C
|
|
1.20
|
N120A013A
|
N120A025A
|
N120A047A
|
N120A090C
|
N120A142C
|
N120A293C
|
|
5.00
|
N500A013A
|
N500A025A
|
N500A047A
|
N500A090C
|
N500A142C
|
N500A293C
|
|
| |
